XY233/XY530/XY550/ XY1010
Characteristic:
1, the higher the ink absorption of good, bright color, vivid images, strength characteristics;
2, good flatness, good peeling strength;
3, special requirements: Hardy, flame retardant, anti UV properties.
Use :
Can be used for large-scale outdoor advertising, light boxes, printing materials.
Performance ：
|
Product Model Item |
XY233/18*12 |
XY530/18*12 |
XY550/9*9 |
XY1010/9*9 |
Unit |
|
|
base fabric |
polyester |
|||||
|
threads |
18*12 |
18*12 |
9*9 |
9*9 |
Fd/lnch |
|
|
weight |
340 |
380 |
440 |
510 |
g/m² |
|
|
Tensile Strength
|
Warp Direction |
350 |
550 |
650 |
1350 |
N/5cm |
|
Weft Direction |
250 |
450 |
550 |
1050 |
N/5cm |
|
|
Tear Strength |
Warp Direction |
120 |
160 |
200 |
360 |
N/5cm |
|
Weft Direction |
80 |
140 |
220 |
330 |
N/5cm |
|
|
Peeling Strength |
Warp Direction |
30 |
35 |
35 |
35 |
N/5cm |
|
Weft Direction |
30 |
35 |
35 |
35 |
N/5cm |
|
|
Applicable Temperature |
-30-70 |
℃ |
||||
|
Width |
1.02-3.20 |
M |
||||
|
Remark: The company can meet special demands of customers according to regulation of the contract. |
||||||
